Maximum glazing: 35 mm.

Maximum accoustic insulation Rw=45 dB

Uw from 1,3 (W/m²K)

Please consult typology, dimensions and glass

Open In:

-practicable  1 or 2 sashes

-turn-tilt 1 or 2 sashes

-hinged

-parallel tilt

SECTIONS

· Frame – 70 mm.

· Sash – 69 mm.

PROFILE THICKNESS

Window 1,5 mm.


Polyamide strip length

· Frame – 35 mm.

· Sash – 16 & 20 mm.

MAXIMUM DIMENSIONS

Width(L)= 1.600 mm.

Height(H)= 2.800 mm.

*Single sash window, turn-tilt


Maximum weight/sash 150 Kg.

Please consult regarding maximum weight
and dimensions for other opening types

Air permeability (EN 12207:2000):

CLASS 4

Water tightness (EN 12208:2000):

CLASS E1500

Wind resistance (EN 12210:2000):

CLASS C5

Reference test 1,30 x 1,55 m., 1 sash.

Possibility of dual colour

Colour powder coating (RAL, mottled & rough)

Wood effect powder coating

Anti-bacterial powder coating

Anodized
